These are boiler plates that stand out for their strength and toughness, thanks to which they ensure reliable and safe use in pressure equipment. Their quality, processing requirements and properties are governed by ASTM/ASME regulations. Thanks to their properties, boiler plates according to ASTM/ASME are widely used in a number of industries, including refinery applications.
Need more information? Leave us your contact information and we will get back to you within 3 days.
Properties and uses of boiler plates according to ASTM/ASME
Boiler plates stand out especially for their strength, toughness and high ductility. They are very weldable and machinable, which makes them ideal for the production of storage tanks and boilers of curved shape. The relatively high yield strength and tensile strength allow the steel to withstand high stress and prevent deformation, thus reducing the risk of material leakage and thus the possible negative impact on the environment. Technical requirements of sheets are specified by the ASTM standard, or ASME – ASTM is denoted by the letter A before the numbers and covers the general properties of the material, ASME (marked SA) is based on ASTM and specifies requirements directly for pressure applications, specifically the BPVC = Boiler & Pressure Vessel Code standard.</p >
The properties of sheet metal offer a wide range of uses across various industries. It is suitable for the production of various containers that are under pressure. You will meet them at above-ground and underground storage tanks or transport tank cars for chemicals, fuels, gases and various liquids. Individual qualities withstand low and medium temperatures, but also high ones. Boiler plates according to ASTM/ASME can be used in the chemical, gas, oil or energy industry.
Choose from a wide range of sizes. We supply sheets in the following dimensions:
- length: max. 18,000 mm,
- width: 1000-3200mm,
- thickness: 5-100 mm,
- weight: max. 12,500 kg.
The stated dimensions are only approximate. The resulting appearance depends on the combination of individual parameters and material specification. Upon agreement, we are able to produce sheet metal up to a length of 21,000 mm and a thickness of 200 mm. For more information contact us.
Basic characteristics of individual qualities
| Steel brand | Grade | Minimum yield strength ReH [MPa] |
Strength limit Rm [MPa] |
Minimum ductility [%] |
Minimum impact work KV [°C/J] |
Thickness [mm] |
|---|---|---|---|---|---|---|
| A/SA 285 | A | 165 | 310-450 | 27/30 | 4/14 | 5-502) |
| B | 185 | 345-485 | 25/28 | 10/14 | 5-502) | |
| C | 205 | 380-515 | 23/27 | 16/14 | 5-502) | |
| A/SA 515 | 60 (415) | 220 | 415-550 | 21/25 | 1) | 5-803) |
| 65 (450) | 240 | 450-585 | 19/23 | 1) | 5-803) | |
| 70 (485) | 260 | 485-620 | 17/21 | 1) | 5-803) | |
| A/SA 516 | 55 (380) | 205 | 380-515 | 23/27 | -51/18 | 5-803) |
| 60 (415) | 220 | 415-550 | 21/25 | -51/18 | 5-803) | |
| 65 (450) | 240 | 450-585 | 19/23 | -51/18 | 5-803) | |
| 70 (485) | 260 | 485-620 | 17/21 | -46/20 | 5-803) | |
| A/SA 537 class 1 |
- | 345 | 485-620 | 18/22 | -62/20 | 5-803) |
Maximum carbon equivalent value according to the relationship
by agreement
- Test temperature and min. value of bump work by agreement
- According to the standard
- Higher thickness up to 100 mm by agreement
Realizations
Petrochemical column for MOL, Hungary
This is a contract for one of the largest companies in the petrochemical industry, MOL.
Year of implementation: 2023. Consumed material: approx. 400 tons of boiler plates according to ASME – SA 516 Gr.70.
